The RAZOR 180 ARC Welder is a powerful and professional STICK (MMA) machine that is designed to be taken on the worksite or the workshop. It is packed full of advanced features including hot start, arc force and anti-stick. It is capable of a DC Lift Arc TIG for more versatility.
We offer a 5-year warranty to reflect our confidence in this machine
Package Includes:
- RAZOR ARC 180 PFC Welder
- 4m Twist Lock Electrode Holder
- 4m 300 Amp Earth Clamp & Lead
- Operating Manual
Specifications:
MACHINE SPECIFICATIONS
PRIMARY INPUT VOLTAGE
240V Single Phase
SUPPLY PLUG
15 AMP
Ieff (A)
14.7
RATED OUTPUT
20A/20.8V - 180A/27.2V
NO LOAD VOLTAGE (V)
78
PROTECTION CLASS
IP23S
INSULATION CLASS
H
MINIMUM GENERATOR (kVA)
10.0
DINSE CONNECTOR
35/50
STANDARD
AS/NZ60974-1
SUITABLE MATERIAL
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze / MMA: Mild Steel, Stainless Steel, Cast Iron
WARRANTY (Years)
5
TIG SPECIFICATIONS
TIG FUNCTION TYPE
DC Lift Arc
TIG WELDING CURRENT RANGE
10-180A
TIG DUTY CYCLE @ 40°C
25% @ 180A, 60% @ 116A, 100% @ 90A
TIG WELDING THICKNESS RANGE
1-6mm
STICK SPECIFICATIONS
STICK WELDING CURRENT RANGE
20-180A
STICK DUTY CYCLE @ 40°C
20% @ 180A, 60% @ 104A, 100% @ 81A
STICK ELECTRODE RANGE
2.5-4.0mm
STICK WELDING THICKNESS RANGE
2-10mm
SIZE & WEIGHT
DIMENSIONS (mm)
370×125×255 mm
WEIGHT (kg)
5.8
MACHINE FEATURES
VRD
YES
