Get greater control over your welds with the VIPER MULTI 165. This multi-process MIG, TIG and STICK machine comes ready with synergic programs, as well as a number of settings — like Inductance — that gives you complete control over your arc.
Package Includes:
- VIPER MULTI 165 MIG/TIG/STICK Welder
- 3m SB15 MIG Torch
- 3m Twist Lock Electrode Holder
- 300 Amp Earth Clamp & Lead
- Argon Flowmeter
- 2m Gas Hose Complete with fittings
- Operating Manual
Features:
Synergic MIG Control
The clever Synergic MIG control takes the guesswork out of your settings. Simply select your wire size and wire type,
and adjust your amperage to suit your work piece. The program works with mild steel, stainless steel, flux-cored and aluminium wires.
Gas & Gasless MIG
This machine supports both gas-shielded MIG and gasless MIG wire, meaning you can easily run mild steel, stainless steel & flux-cored MIG wire.
Multi-Process Welding
This three-in-one machine, lets you perform MIG, TIG and STICK welding all on one machine. There is no need to swap between machines, saving you time and setup.
10 AMP Plug
Plug in and play. A 10 AMP power plug can be used on any domestic outlet. It’s perfect for the DIY home handyman or the professional welder looking for a machine that can be used almost anywhere.
Lightweight & Portable
Weighing just 9.8kg, the VIPER Multi 165 is ready to go anywhere you need it.
Feature Video
Check out the full set of features on the VIPER Multi 165 in the video below
- PRIMARY INPUT VOLTAGE:
- 240V Single-Phase
- SUPPLY PLUG:
- 10 AMP
- Ieff (A):
- 10.0
- RATE OUTPUT:
- 30A/15.5V - 165A/22.3V
- NO LOAD VOLTAGE (V):
- 64
- PROTECTION CLASS:
- IP21S
- INSULATION CLASS:
- H
- MINIMUM GENERATOR (kVA):
- 9.0
- DINSE CONNECTOR:
- 35/50
- STANDARD:
- AS/NZ60974-1
- SUITABLE MATERIAL:
- Mild Steel, Stainless Steel, Cast Iron, Silicon Bronze, Aluminum, Copper
- WARRANTY:
- 2 Years
- MIG WELDING CURRENT RANGE:
- 30-165A
- MIG DUTY CYCLE @ 40°C:
- 10% @ 165A / 60% @ 68A / 100% @ 52A
- MIG WIRE SIZE RANGE:
- 0.6-0.9mm
- MIG WIRE SPOOL SIZE:
- 1kg / 5kg
- MIG WELDING THICKNESS RANGE:
- 1-8mm
- DRIVE ROLLER SIZE:
- 30/10
- TIG FUNCTION TYPE:
- DC Lift Arc
- TIG WELDING CURRENT RANGE:
- 20-160A
- TIG DUTY CYCLE @ 40°C:
- 10% @ 160A / 60% @ 65A / 100% @ 50A
- TIG WELDING THICKNESS RANGE:
- 1-6mm
- STICK WELDING CURRENT RANGE:
- 20-140A
- STICK DUTY CYCLE @ 40°C:
- 10% @ 140A / 60% @ 58A / 100% @ 45A
- STICK ELECTRODE RANGE:
- 2.5-3.2mm
- STICK WELDING THICKNESS RANGE:
- 2-8mm
- DIMENSIONS (mm):
- 513x206x391mm
- WEIGHT (kg):
- 9.8
- WIRE DRIVE:
- Standard
- VRD:
- Yes
- WIRE INCH:
- Yes
- INDUCTANCE CONTROL:
- Yes
- THERMAL OVERLOAD PROTECTION:
- Yes
