The 3M Speedglas G5-03 TW Pro Welding Helmet delivers the optical quality synonymous with the Speedglas brand thanks to True-View technology, an extra bright light state (shade 2.5), industry-leading arc detection (>1 amp), and new TAP Technology to switch quickly between weld, cut, and grind settings. This non-respiratory helmet can also be customised to the exact preference of each welder courtesy of an ergonomic head harness with 6 points of adjustment, configurable head and neck covers, and an optional task light.
Customise Your Fit:
Designed for ultimate comfort and a custom fit, the G5-03 Pro shares the same market-leading head harness as the G5-01. With multiple points of adjustment, dual comfort paddles, perfect weight distribution and an extra comfort pad, welders can find their perfect fit.
Features:
Suitable Across a Range of Welding Applications:
Built for professional welders, the G5-03TW lens has shades 2.5, 5, 8-13 and is suitable for welding, grinding, cutting, and tack welding - even with a completely hidden arc. Welders can choose to switch between their weld, grind and cut modes by utilising new TAP functionality!
Bluetooth Functionality:
The Speedglas G5-03TW auto-darkening lens features Bluetooth connectivity, allowing welders to program lens settings including memory modes, as well as access welding statistics and user manuals.
New TAP Technology:
Exclusive TAP Technology allows you to easily switch between weld, cut and grind modes by simply tapping the outside of your Speedglas welding helmet - even with a gloved hand!
Advanced True-View Optics:
Speedglas True-View optics need to be seen to be believed. With an extra light 2.5 shade, the welding lens provides even greater clarity and contrast than ever before - giving you clearer views during set-up and inspection of just completed welds.
Customisable Welding Protection
Optimise your welding protection with a range of configurable extra coverage options. Choose from extended neck and head covers, to protect against sparks and spatter.
- Relevant Welding Helmet Standards:
- Eye Protection - AS/NZS1338.1, Face Protection - AS/NZS1337.1 (High Impact)
- Speedglas TrueView Welding Lens:
- Yes
- Variable Colour Technology:
- No
- Stick Welding:
- Yes
- MIG Welding:
- Yes
- TIG Welding:
- Yes (industry leading detection down to 1 Amp)
- Grinding Feature:
- TAP Technology (shade 2.5)
- Memory Mode (Set-and-Forget):
- Yes
- SideWindow Peripheral Vision:
- Yes
- Hidden Arc Mode:
- Yes
- Welding Lens Viewing area:
- 73 x 109mm + Side Windows
- Variable Dark Shades:
- Shade 5, 8-13
- Light State:
- TrueView Shade 2.5
- UV Protection:
- Shade 13 (permanent)
- Switching time, light-dark:
- 0.1 ms (+23 C)
- Delay (switching time, dark-light):
- 50-1300 ms
- Blue-Tooth Enabled:
- Yes
- Optional Task Light:
- Yes
- Comfort Exhaust Vents:
- No
- Head Harness:
- New G5-03 Pro Head Harness
- Safety Helmet:
- No
- Required minimum protection factor:
- N/A
- Air flow Level:
- N/A
- Adjustable Air Control:
- No
- Adflo Battery Run Time:
- N/A
- Adflo Battery Charge Time:
- N/A
